    Three Way Dual Shut-Off Valves

    Add to Quote
    SKU: N/A Category:
    henrytechlogo 150px
    Conn Size & Inlet and Outlet

    , , , , , , , ,

    Brand

    Henry Technology

    henrytechlogo 150px

    Specifications

    Type Part No Inlet Conn Size

    (inch)

    		 Outlet Conn Size

    (inch)

    		 Dimensions (mm) Drawing reference Weight (kg) Kv (m³/hr) CE Cat
    A B C D E
    92 923 3/8 FPT 3/8 FPT 70 52 64 32 93 fig.1 0.51 2.80 SEP
    92 923M 3/8 MPT 3/8 FPT 70 52 90 57 93 fig.2 0.57 2.80 SEP
    92 925 1/2 FPT 1/2 FPT 70 52 64 32 93 fig.1 0.47 2.83 SEP
    92 925M 1/2 MPT 1/2 FPT 70 52 97 65 93 fig.2 0.57 2.83 SEP
    92 927 3/4 FPT 3/4 FPT 70 52 70 35 100 fig.1 0.70 3.48 SEP
    802* 8021A 1/2 FPT 1/2 FPT 92 59 86 44 146 fig.1 1.47 4.78 SEP
    802* 8022A 3/4 FPT 3/4 FPT 92 59 86 44 146 fig.1 1.33 7.60 SEP
    802* 8024-CE 1 FPT 1 FPT 148 94 99 51 191 fig.1 3.70 10.07 SEP (Cat I)
    802* 8025-CE 1 1/4 FPT 1 1/4 FPT 148 94 99 51 191 fig.1 3.25 14.36 Cat I (Cat II)

    *Suitable for Ammonia. Brackets indicate CE category for Ammonia use
